7614-6002PL

HDR SOCKET 14 POS BTB VERT TH

Manufacturer: 3M

Quality Control: Learn More

Connector Header 14 position 0.100"" (2.54mm)

Series: 76RoHS Status: RoHS CompliantManufacturer Lead Time: 12 week(s)Product Status: ActivePackaging: BulkDatasheet:

Download Free CAD Model:

Technical Details:

Features	-
Packaging	Bulk
Connector Type	Header
Voltage Rating	-
Current Rating (Amps)	-
Mounting Type	-
Number of Positions	14
Number of Rows	2
Style	-
Operating Temperature	-
Contact Type	Male Pin
Fastening Type	-
Number of Positions Loaded	All
Termination	Solder
Ingress Protection	-
Material Flammability Rating	-
Contact Material	-
Insulation Color	Gray
Pitch - Mating	0.100"" (2.54mm)
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	8.00µin (0.203µm)
Contact Finish - Post	Gold
Contact Shape	-
Contact Length - Post	0.110"" (2.80mm)
Insulation Height	-
Shrouding	-
Overall Contact Length	-
Insulation Material	-
Row Spacing - Mating	0.100"" (2.54mm)
Contact Length - Mating	-
